ALL-IN-ONE PC

DITENG TECHNOLOGY LIMITED

Bar LCD

Bar LCD

Customized bar LCD screen

Category ALL-IN-ONE PC Tags Cotton, Pure, Reversible to denim

Product Description

Customized bar LCD screen:
We can customize various bar LCD screens for customers;
No need to worry about embarrassing size.

Details

REF	WATLA
Composition	87% Polivinyl, 6,5% PES, 6,5% CO
Width	140
Height	100

21.5 Inch TFT-LCD

21.5 Inch TFT-LCD

Contents	Description
Display outline size	495.6 mm (H ) x 292.2 mm ( V ) x 10.7 mm ( D )
VA size	476.64 mm ( H ) x268.11 mm ( V )
Resolution	1920 x RGB x 1080
With /Without Touch screen	CTP
Bezel width (L/R/U/D)	7.9/7.9/10.5/10.5
Pixel Pitch	0.24825(H) x 0.24825(V) mm
Color	16.7M
Luminance	Typ 1000 nits

12.3 Inch TFT-LCM

12.3 Inch TFT-LCM

Contents	Description
Display outline size	308.1 mm (H ) x 130.0 mm ( V ) x 15.0 mm ( D )
VA size	292.032 mm ( H ) x109.512 mm ( V )
Height	100
Resolution	1920 RGB ( H ) x 720 ( V )
With /Without Touch screen	CTP
Interface	2Port LVDS
Pixel Pitch	0.1521(H)x 0.1521 mm ( V )
Color	16.7M
Luminance	Typ 850 nits

86.0 Inch TFT-LCD

86.0 Inch TFT-LCD

REF	WATLA
Contents	Description
Display outline size	1932 mm (H ) x 1103 mm ( V ) x 40.0 mm ( D )
VA size	1895.04 mm ( H ) x1065.96 mm ( V )
Resolution	3840 x 2160
With /Without Touch screen	CTP
Display Colors	10-bit(D),1.07 Billion colors
Pixel Pitch	0.4935(H) x 0.4935(V) mm
Surface Treatment	Anti-Glare,2H
Luminance	Typ2000 nits

Reviews

There are no reviews yet.

Be the first to review “Bar LCD”

Bar LCD

Next

86.0 Inch TFT-LCD
